Khoom Description
Lub ib leeg mast txhuas ntsug tus txiv neej nqa ntau yam ntawm 4m ~ 10m.lt yog tsim los rau tag nrho cov sab hauv tsev aerial ua hauj lwm tej yaam num. Qhov loj me me tso cai rau nws nkag mus rau ntau qhov chaw kaw, yooj yim hla lub qhov rooj thiab hloov mus rau elevators. Nws muaj qhov hnyav hnyav heev, tsis yog - khij lub log tsheb, thiab cov stabilizers nrog roj hmab, uas tso cai rau nws ua haujlwm ntawm ntau qhov chaw tsis yooj yim. Lub tshuab tuaj yeem thauj khoom yooj yim, txav mus los, thiab teeb tsa los ntawm ib tus neeg, lossis rub los ntawm lub tsheb lossis lub tsheb, thiab tsuas yog yuav tsum tau saib xyuas tsawg kawg nkaus. Nws yog tus nqi zoo thiab txawm tias kim tsawg dua li koj lub zos zoo sib xws.
Khoom Tsis muaj
|
Qauv |
HLB04-1 |
HLB06-1 |
HLB08-1 |
HLB 10-1 |
|
Max. Ua haujlwm siab |
6m |
8m |
10m |
12m |
|
Max. Platform Qhov siab |
4m |
6m |
8m |
10m |
|
Chaw thau khoom muaj peev xwm |
120 kg |
120 kg |
120 kg |
100 kg |
|
Cov neeg nyob |
1 |
1 |
1 |
1 |
|
Platform Dimension |
600 * 600 hli |
600 * 600 hli |
600 * 600 hli |
600 * 600 hli |
|
Zuag qhia tag nrho Dimension |
1150 * 800 * 1650 hli |
1150 * 800 * 1800 hli |
1250 * 830 * 1980 hli |
1330 * 830 * 2100 hli |
|
Qhov hnyav |
195kg ua |
230kg ua |
300 kg |
360kg ua |
|
Lifting lub cev muaj zog |
220V / 1.1kw |
220V / 1.1kw |
220V / 1.1kw |
220V / 1.1kw |
|
Lifting ceev |
4-6m / min |
4-6m / min |
4-6m / min |
4-6m / min |
|
Yam tsawg kawg nkaus hauv av clearance |
0.05m |
0.05m |
0.05m |
0.05m |
|
Wheelbase |
1.1m |
1.1m |
1.29m |
102m |
|
Lub log |
6 ntiv |
6 ntiv |
6 ntiv |
6 ntiv |
Khoom Paub meej
Chain Link System
Dual -chain kis tau tus mob tsim kom muaj peev xwm txhawb nqa, du thiab ruaj khov
Kev Txhawb Nqa Kev Nyab Xeeb
Muaj nuj nqi raws li lub guardrail kev txhawb nqa bracket, muab qhov ruaj khov thiab ruaj khov
Master tswj vaj huam sib luag nrog compreh
Master tswj vaj huam sib luag nrog kev ua haujlwm zoo Intuitive tsim rau kev lag luam meej thiab kev tswj xyuas yooj yim
Premium Aluminium Alloy
Siab -strength profiles extruded nrog 3500-tuj xovxwm rau structural rigidity.Superior corrosion kuj rau ncua kev pab cuam lub neej
Foldable Support Legs
Chaw-txuag tsim-- Ob txhais ceg quav thaum tsis siv
Hnav-Resistant Polyurethane Log
Maneuverable heev & pem teb-tus phooj ywg, tshwj xeeb durability nrog ntxiv dag zog tiv thaiv kev nyab xeeb & txhim khu kev qha kev ua tau zoo rau lub sijhawm ntev- siv
Khoom nta
Load Capacity
Lub peev xwm ntawm 200kg ua kom ntseeg tau tias lub nqa tuaj yeem tswj tau ntau yam khoom siv thiab khoom siv, ua rau nws tsim nyog rau ntau yam kev lag luam.
Max Lifting Qhov siab
Nrog rau qhov siab tshaj plaws nqa qhov siab txog li 14 meters, lub nqa nqa tau nkag mus rau thaj chaw siab, txhim kho nws cov txiaj ntsig hauv kev tsim kho, kev saib xyuas, thiab lwm yam haujlwm siab.
Hydraulic Lift Drive
Lub tshuab nqa hydraulic ua kom du thiab ruaj khov nqa, muab kev ua tau zoo thiab kev ua haujlwm yooj yim rau cov neeg siv.
Aluminium Alloy Kev Tsim Kho
Tsim los ntawm aluminium alloy, lub nqa yog ob qho tib si hnyav thiab ruaj khov, ua kom yooj yim rau maneuver thiab tiv taus corrosion, ncua nws lub neej ua haujlwm.
Khoom daim ntawv thov
Tuam txhab Profile
Kev mob siab rau kev tswj hwm nruj thiab kev xav zoo rau cov neeg siv khoom, peb cov neeg ua haujlwm paub txog ib txwm muaj los tham txog koj cov kev xav tau thiab ua kom tag nrho cov neeg siv khoom txaus siab. Nyob rau hauv xyoo tsis ntev los no, peb lub tuam txhab tau qhia ib tug series ntawm advanced cov cuab yeej rau lub crane tshuab ntau lawm. Tsis tas li ntawd, peb tau txais daim ntawv pov thawj raws li CE, ISO, SGS. Muag tau zoo nyob rau hauv txhua lub nroog thiab cov xeev nyob ib ncig ntawm Tuam Tshoj, peb cov khoom tseem raug xa tawm mus rau cov neeg siv khoom hauv cov teb chaws thiab cheeb tsam xws li Europe, South America, Middle East, Australia, Africa thiab Southeast Asia. Peb ib txwm muab cov khoom lag luam zoo heev thiab tau txais cov lus pom zoo los ntawm txhua tus neeg siv khoom. Peb kuj txais tos OEM thiab ODM xaj. Txawm hais tias xaiv cov khoom tam sim no los ntawm peb cov catalog lossis nrhiav kev pabcuam engineering rau koj daim ntawv thov, koj tuaj yeem tham nrog peb lub chaw pabcuam cov neeg siv khoom txog koj qhov kev xav tau.
Peb Daim Ntawv Pov Thawj
Packing & Delivery
FAQ
5 hnub rau nkoj yog nyob rau hauv Tshuag, 25 hnub yog tias nws yuav tsum tau rov ua dua - khoom.
Huali muaj kev nplua nuj los xaiv cov cuab yeej tsim nyog rau koj, raws li peb tau nyob hauv kab no dhau 10 xyoo. Ntxiv mus, peb cov khoom muaj kev sib tw, ob qho tib si hauv cov khoom zoo thiab tus nqi.
Feem ntau, lub sijhawm lav khoom yog 12 lub hlis rau cov khoom tseem ceeb txij li thaum koj tau txais nws.
Thov xa daim duab lossis yees duab txog qhov tawg rau peb, peb tuaj yeem muab kev pabcuam thiab cov khoom seem dawb ntawm qhov tseem ceeb hauv 12 npauj.
Peb tsis tsuas yog muab cov khoom txheem, tab sis kuj txhawb cov khoom customized.
